CODE: FRP-004
EFBI Activated carbon filters are used for the treatment of dissolved gases, residues and organic substances that give unwanted chlorine, color, taste, odor in water. Activated carbon is charcoal-like but has a very large surface area (1000-1500..
EFBI activated carbon filters are used to remove unwanted chlorine, color, taste, odor-causing dissolved gases, impurities, and organic substances from water. Activated carbon is a charcoal-like material with a very large surface area (1000–1500 m²/g).
TECHNICAL SPECIFICATIONS
WCY brand FRP tank
Aqualine brand coconut-based activated carbon
Maximum operating pressure 6 bar
Time-controlled backwash
Pneumatic actuator-operated butterfly valves (Optional electric actuator option)
Octopus diffuser in the lower collection structure
PVC-U piping (epoxy-coated frame)
Sampling valves and pressure gauges at system inlets and outlets
PLC-based Siemens Logo control panel (Optional touchscreen option)
Electrical: 220V / 50 Hz / 1 phase
The customer is responsible for providing the dry instrument air required for the operation of the pneumatic valves. The recommended compressor capacity is a minimum of 100 L/min @ 8 bar.
